Four Post Cargo Lift

Lifting height 2.4-6.5m (7.9-21.3ft)
Loading capacity 1000-5000kg (2204-11023lbs)
Platform size 2* 2m (6.5*6.5ft)

FOUR POST CARGO LIFT

Four-post Cargo Lift is mainly used to provide fast, efficient, convenient and safe access for goods to reach mezzanines, basements, and any levels in multi-storey buildings. It is widely used in indoor or outdoor workplaces of the buildings and warehouses, lifting goods or pallets among different vertical floors.

INTRODUCTION

Four-post Cargo Lift is mainly used to provide fast, efficient, convenient and safe access for goods to reach mezzanines, basements, and any levels in multi-storied buildings.

FOUR POST CARGO LIFT FOR SALE

ModelLoad CapacityPlatform SizeTravel HeightPit DepthDimension
LRL3-2.43000kg2*2m2.4m350mm2.8*2.16*4.9m
LRL2-52000kg2.1*1.2m5m350mm2.85*1.36*7.5m
LRL1-4.51000kg2.1*1.5m4.5m350mm2.75*1.65*7m
LRL5-6.55000kg2.2*1.6m6.5m350mm3*1.75*9m
LRL3-6.53000kg2.2*1.9m6.5m350mm2.95*2.05*9m
Four-post Cargo Lift is customizable in loading capacity, platform size and travel height.

APPLICATION

four post cargo lift project - MORN LIFT (3)
cargo lift with four post project - MORN LIFT
four post goods lift project - MORN LIFT
four post cargo lift project - MORN LIFT (2)

Cargo lift is widely used in indoor or outdoor workplaces of the buildings and warehouses, lifting goods or pallets among different vertical floors.

High Grade Parts Ensure High Quality of Four post cargo lift

All the parts we use are first-class quality and well-known brands. The parts are a standard model with item code, which are very convenient to be replaced. Delivery is also fast for parts.

Four Post Cargo Lift Specifications

ModelLoad CapacityPlatform SizeTravel HeightPit DepthDimension
LRL3-2.43000kg2*2m2.4m350mm2.8*2.16*4.9m
LRL2-52000kg2.1*1.2m5m350mm2.85*1.36*7.5m
LRL1-4.51000kg2.1*1.5m4.5m350mm2.75*1.65*7m
LRL5-6.55000kg2.2*1.6m6.5m350mm3*1.75*9m
LRL3-6.53000kg2.2*1.9m6.5m350mm2.95*2.05*9m
Four-post Cargo Lift is customizable in loading capacity, platform size and travel height.

MORE CHOICE

Four-post Cargo Lift is widely used in indoor or outdoor places of the buildings and warehouses to lift goods or pallets between floors.
